Future proof your alarm communication

Following the successful series IRIS-800, IRIS Touch and IRIS Touch NG, IRIS-4 is now the fourth generation of the Alarm over IP product range.

The IRIS system provides a simple, reliable and proven way to convert existing, analogue, security installations to modern digital IP communications, and has become one of Europe’s most widely used security system – trusted by security installers, monitoring centre operators and end-users.

Now, with support for 4G and a new processor enabling double the capacity and speed – improvements making the IRIS-4 terminal family future proof in regards to changes in the mobile networks and ready for new technologies.

All IRIS-4 products are tested and certified by the renowned VdS laboratories to the latest and highest European standards for alarm transmission.



IRIS-4 160

IRIS-4 2 Series

IRIS-4 4

IRIS-4 4 Series

IRIS-4 6

IRIS-4 6 Series

Specifications AddSecure IRIS-4 Series

FEATURE 160 200 220 240 400 420 440 620 640
Fire retardant enclosure ■ ■ ■ ■ - - - - -
Battery backup >15h - - - - - - - -
Touch screen - ■ ■ ■ ■ ■ ■ - -
Security Grade 2 3 3 3 4 4 4 4 4
EN54-21 CPR Fire approved - - - - ■ ■ ■ - -
Ethernet ports 1 - 1 1 - 2 2 1 1
WiFi ■ - - - - - - - -
2/3/4G ■ ■ - ■ ■ - ■ - ■
Dial Capture ■ ■ ■ ■ ■ ■ ■ - -
Relays 3 3 3 3 4 4 4 4 4
Inputs (pins) 4 4 4 4 4 standard +12 with add-on expansion board 4 standard +12 with add-on expansion board 4 standard +12 with add-on expansion board 6 6
Serial RS485 ■ ■ ■ ■ ■ ■ ■ ■ ■
Serial TTL ■ ■ ■ ■ ■ ■ ■ ■ ■
RS232 (basic ) ■ ■ ■ ■ 1x full or 2x basic 1x full or 2x basic 1x full or 2x basic 2x basic 2x basic
SMS text messaging ■ ■ - ■ ■ - ■ - ■
Multi language menus ■ ■ ■ ■ ■ ■ ■ ■ ■
VoIP & SIP services ■ ■ ■ ■ ■ ■ ■
CAN bus - - - - ■ ■ ■ - -
Certifications
EN 50131, EN 50136 VdS Certified)
The terminals are compliant with the requirements of European standards:
EN 50131-1: 2006+A2:2017 & EN 50131-10:2014
EN 50136-1: 2012 & EN 50136-2: 2013
Environmental Class II

Secure SIM Subscription

This is our subscription for alarm transmission which ensures access to the mobile network and your Alarm Receiving Center. It also comes with support by our competent alarm communication helpdesk. PRICE 5 € per month, VAT not included.
